An overview of the PSF variation as a function of wavelength (UV clocked)
Note: 1 pix ~ 3.2 A resolution. Scale given is size of square in X and Y.The following plots were prepared using the Zemax optical model.
2100A========== scale 32um (3 pix)
2350A========== scale 32 um
2600A========== scale 32um
3200A========== scale 32 um
3500A========== scale 32 um
3800A ========== scale 64 um (6 pix)
4200A========== scale 64 um
4600A========== scale 128 um (12 pix)
5000A========== scale 128 um (12 pix)
5400A========== scale 256 um (23 pix)
5800A========== scale 256 um
6200A========== scale 256 um
6600A========== scale 256 um (23 pix)
7000A========== scale 512 um (46 pix)
